Leybold

Leybold TURBOVAC MAG.DRIVE Digital Controller

Name: Leybold TURBOVAC MAG.DRIVE Digital Controller
Brand: Leybold
Price: 4249.00 USD
Availability: InStock

Condition: Refurbished

In Stock

The Leybold TURBOVAC MAG.DRIVE digital controller is a high-performance drive unit engineered to power, control, and levitate Leybold TURBOVAC MAG series magnetically levitated turbomolecular pumps. Featuring advanced digital signal processing and active 5-axis magnetic bearing management, it delivers precise rotor position control, low vibration, and automated speed regulation. Built with comprehensive diagnostic software interfaces, internal power conditioning, and robust fault-monitoring logic, the MAG.DRIVE digital controller ensures stable, hydrocarbon-free high-vacuum operation across demanding semiconductor, industrial coating, and analytical applications.

Technical Specifications

Parameter	Specification Details
Model / Series	TURBOVAC MAG.DRIVE Digital
Manufacturer	Leybold Vacuum
Compatible Pumps	Leybold TURBOVAC MAG W 300 / MAG W 600 / MAG W 1300 / MAG W 2200 / MAG 2000 Series
Control Architecture	Digital 5-Axis Active Magnetic Levitation & Motor Inverter Drive
Input Voltage	100–240 VAC, 1-Phase, 50/60 Hz
Output Frequency	Variable High-Frequency Drive (Up to 1,000 Hz)
Interface Options	RS-232C, RS-485, Profibus / DeviceNet, Remote Parallel I/O, Relay Interlocks
Cooling Method	Forced Air (Internal Fan Cooled)
Enclosure Format	19" Rack-Mount Chassis (3U) / Benchtop
Dimensions	Approx. 5.2" H x 19.0" W x 15.7" D (133 mm x 483 mm x 400 mm)
Weight	~26.5 lbs (12 kg)
