Leybold Turbovac 250i, 100 ISO-K Turbomolecular Vacuum Pump
The Leybold Turbovac 250i delivers superior performance in a compact, efficient package designed for demanding high-vacuum applications. This advanced turbomolecular pump offers exceptional throughput and reliability, making it ideal for semiconductor processing, research facilities, and industrial coating systems. With its optimized rotor design and advanced bearing technology, the Turbovac 250i ensures consistent performance and minimal maintenance requirements.
|
Specification |
Details |
|
Pumping Speed (N₂) |
225 l/s |
|
Pumping Speed (Ar) |
210 l/s |
|
Pumping Speed (He) |
250 l/s |
|
Pumping Speed (H₂) |
210 l/s |
|
Gas Throughput (N₂) |
6 mbar*l/s |
|
Ultimate Pressure |
< 8 x 10⁻⁸ mbar |
|
Max. Forevacuum Pressure |
14 mbar |
|
Operating Speed |
72,000 min⁻¹ |
|
Run-up Time |
2 minutes |
|
Power Consumption (max) |
240 W |
|
Power Consumption (ultimate pressure) |
7 W |
|
High-vacuum Connection |
100 ISO-K |
|
Forevacuum Connection |
16 KF |
|
Cooling |
Convection (standard), Air or water (optional) |
|
Maximum Bake-out Temperature |
100°C |
|
Purge Gas Connection |
G 1/8" |
|
Venting Connection |
G 1/8" |
The Turbovac 250i features exceptional compression ratios (1x10¹¹ for N₂ and Ar) and rapid pump-down capabilities, ensuring optimal vacuum conditions for your most critical processes. Its energy-efficient design maintains low power consumption during operation while delivering consistent, high-performance vacuum levels.
