Leybold MAG W 1300 iP Turbomolecular Pump
The MAG W 1300 iP turbomolecular pump delivers exceptional performance for demanding high-vacuum applications in semiconductor manufacturing and research environments. This water-cooled pump combines high pumping speeds with excellent compression ratios, making it ideal for processes requiring precise vacuum control and contamination-free environments. With its Profibus interface, the MAG W 1300 iP offers seamless integration into modern automation systems while maintaining reliable operation under challenging conditions.
|
Specification |
Details |
|
Pumping Speed (N₂/Ar/He/H₂) |
1100/1050/1220/1130 l/s |
|
High-vacuum Connection |
DN 200 ISO-F |
|
Forevacuum Connection |
DN 40 KF |
|
Ultimate Pressure |
< 1 × 10⁻⁸ mbar |
|
Compression Ratio N₂/Ar |
1 × 10⁸ |
|
Compression Ratio He/H₂ |
2 × 10⁵/8 × 10³ |
|
Gas Throughput N₂/Ar |
20/15 mbar*l/s |
|
Operating Speed |
37,800 min⁻¹ |
|
Run-up Time |
5 minutes |
|
Power Consumption (max/ultimate) |
750/150 W |
|
Cooling Method |
Water |
|
Maximum Bake-out Temperature |
80°C |
|
Purge Gas/Venting Connection |
DN 16 KF |
|
Max. Forevacuum Pressure (N₂) |
4 mbar |
This high-performance turbomolecular pump excels in critical vacuum applications where consistent performance and cleanliness are paramount. The water cooling system ensures thermal stability during continuous operation, while the integrated Profibus communication enables advanced monitoring and control capabilities.
