Leybold RUVAC WAU 251 Roots Vacuum Booster Pump
The RUVAC WAU 251 represents the pinnacle of Leybold's roots vacuum technology, engineered specifically for demanding semiconductor manufacturing and industrial coating applications. This high-performance booster pump delivers exceptional pumping speeds while maintaining precise vacuum levels. With its robust construction and advanced shaft sealing system, the WAU 251 ensures reliable operation in continuous industrial processes where consistent vacuum performance is critical.
|
Specification |
Details |
|
Nominal Pumping Speed |
304 m³/h (179 cfm) |
|
Maximum Effective Pumping Speed |
251 m³/h (148 cfm) |
|
Ultimate Total Pressure |
< 8 x 10⁻⁴ mbar (< 6 x 10⁻⁴ Torr) |
|
Maximum Permissible Pressure Difference |
80 mbar (60 Torr) |
|
Leak Rate |
< 1 x 10⁻⁴ mbar x l/s |
|
Motor Power |
1.4 kW (1.9 hp) |
|
Voltage |
200-208 / 265 / 460 V |
|
Thermal Class |
F |
|
Operating Temperature Range |
+5 to +40°C (+41 to +104°F) |
|
Nominal Speed |
3600 rpm |
|
Maximum Speed |
6000 rpm |
|
Protection Class |
IP 20 |
|
Connection Flanges |
63 ISO-K |
|
Weight |
85/89 kg (187.4/196.2 lbs) |
|
Noise Level |
< 60 dB(A) |
|
Compatible Backing Pump |
TRIVAC D 65 B |
The WAU 251 features a thermally optimized design for consistent performance in demanding industrial environments. Its precision-engineered rotor system and advanced sealing technology ensure minimal maintenance requirements while delivering reliable vacuum performance. The pump's robust construction makes it particularly well-suited for applications in semiconductor manufacturing, where consistent, high-quality vacuum levels are essential.
